JP TRADING CO is one of the leading Abrasive Stainless Steel Grits Suppliers in India.
JP TRADING CO represents “VULKAN INOX GmbH – Germany.
Stainless Steel Grits used in all applications where ferrous residue is a disadvantage or undesired. Stainless Steel Grits GM has a lower hardness than Stainless Steel Grits GH, thereby resulting in its sharp angular edges rounding off in operation. However, the angular form of the grain is mostly retained.
Stainless Steel Grits GM is suitable for use in centrifugal wheel blast machines as well as air pressure systems and finds use in cleaning, roughening, paint removal, deburring, and descaling, Primary application sectors are:
- Corrosion protection application (powder coating/paint)
- Rubber-metal bonding
- Adhesion
- Simple descaling
Technical Data
Chemical Composition: C 1,9 – 2,1%, Cr 30,0 – 33,0%
Apparant density: ~ 4,1 g/cm3
Hardness: ~ 660 HV ~(57 HRC)
Microstructure: Delta-Ferrite with Chromium Carbides
Available Grain sizes
GRITTAL GM mm GRITTAL GM mm
GM 10 0,05 – 0,20 GM 60 0,70 – 1,25
GM 20 0,09 – 0,32 GM 100 1,00 – 1,40
GM 30 0,14 – 0,50 GM 150 1,25 – 1,70
GM 40 0,40 – 0,80 GM 200 1,40 – 2,00
GM 50 0,60 – 1,00 GM 300 1,70 – 3,00
Stainless Steel Grits GH is used in all applications where ferrous residue is a disadvantage or undesired. Heat-treated under an inert gas, GRITTAL GH also retains its angular shape in an operating mix. For all users that prefer the sharpest possible surface profile with a high peak count, this one-of-a-kind blast media offers the best results in regards to quality, coverage performance and efficiency.
Primary application sectors are:
- Wear resistance coating (PTFE, ceramic)
- Corrosion protection application (powder coating/paint)
- Metalizing
- Rubber-metal bonding
- Adhesion
- Descaling
Technical Data
Chemical Composition: C 1,9 – 2,1%, Cr 30,0 – 33,0%
Apparant density: ~ 4,1 g/cm3
Hardness: ~ 800 HV ~ (64 HRC),
Microstructure: Martensitic with Chromium Carbides
Available Grain sizes
GRITTAL GH mm GRITTAL GH mm
GH 10 0,05 – 0,20 GH 60 0,70 – 1,25
GH 20 0,09 – 0,32 GH 100 1,00 – 1,40
GH 30 0,14 – 0,50 GH 150 1,25 – 1,70
GH 40 0,40 – 0,80 GH 200 1,40 – 2,00
GH 50 0,60 – 1,00 GH 300 1,70 – 3,00
